RL-1290 600mm/s 750KG 1.5KW CO2 Laser Engraving And Cutting Machine
Laser Cutting Machine Advantages
1. Adjustable Speed and Power, Smooth and Precise Engraving and
Cutting
2. USB Interface or off USB , U-Flash Disk Supported, Can work
without a PC.
3. Air Assist, Remove heat and combustible gases from the cutting
surface.
4. Embedded Exhaust Fan, Easier intall, Safer transport.
5. Rotary Axis, Engrave any cylindrical object.
6. Cellular platform, Leave no chippings on working area.
7. Intuitive Control Panel, Set Speed, power and more controls
directly from the laser.
8. Water Cooling and Protection System.
9. Lsser position.
10. Emergency Stop Button.
12. Lifting platform is electric control.
13. Drag - and - chain transmission line
Specifications: 1 This model Laser machine uses blocking design, easy to install
and adjust
2 The machine frame in reason, the materials can put into from the
front and behind,it can Exhaust the smoke on the above and below of
the laser machine.
3 It uses offline control system, English LCD, USB interface,
support CAD and CorelDraw output directly.
|
| Parameter |
| Type | RL-1290 |
| Engraving Area | 1200 x 900mm |
| Laser Power | 60w special for engraving |
| Laser Type | CO2 Laser Tube |
| Engraving speed | 0~1000mm/s |
| Cutting speed | 0~600mm/s |
| Resetting positioning accuracy | 0.01mm |
| Cutting depth | Acryl 0-20mm(other depths depend on other materials) |
| Minimum Shaping Character | 1.5×1.5mm |
| Power supply | 220V±10% 50HZ or 110V±10% 60HZ |
| Gross power | 1200W |
| Software supported | ArtCut, CorelDraw, PhotoShop, AutoCAD |
| Graphic format supported | PLT,DXF,BMP,JPG,GIF,PGN,TIF |
| Engraver for Curve surfaces (Yes/No) | No (we can add an Rotary attachment on the Laser Engrave/Cutting
Machine, then the machine can engrave on Cylinder) |
| Water Cooling: (Yes / No) | Yes |
Maximum Height of Materials to Engrave (mm) | 350mm(Up and down by motor) |
| Laser Tube (life hours) | 3000-10000hours |
| Equipment Dimensions | 1830×1500×1240mm |
| Assistant Equipment | Water pump | Exhaust Fan | Aluminum alloy worktable |
| Optional Spare Parts | RF Tube | Rotary System | Cooling water syem | Red Dot Pointer |
| Recommended Spare Parts / Consumables | Laser Tube and Lens
|
Application materials: fabric, leather, rubber, bamboo, crystal, plexiglass, ceramic
tiles, marble, veneer film, cardboard, jade, plastic, ox horn,
wood, rubber, ink pad save the various non-metallic materials such
as shape of the material.
Laser cutting machine Application Fields:
1. It’s widely used in garment material: leather engraving and
cutting, textile engraving, fabric engraving, cloth engraving, shoe
engraving, jeans engraving, carpet engraving and cutting, toy
cutting, woolen cutting, denim engraving and cutting.
2. Advertisement material, such as acrylic engraving and cutting,
plastic engraving and cutting, PVC board engraving and cutting,
rubber plate engraving, seal engraving, organic glass engraving,
plexiglass engraving, marble engraving, granite engraving, Gum
engraving, EVA materials engraving, paper engraving and cutting.
3. Wood material: wood engraving and cutting, MDF engraving,
plywood cutting.
Laser cutting machine Application Industry:
Garment and leather, embroidery, billboards, artistic gifts,
crystal ornaments, paper-cut, bamboo and wooden product, decoration
and upholster industry.
